7.5kw 4mm Hydraulic CNC Press Brake For Metal Plate

Product Details

Place of Origin: China

Brand Name: AOXUANZG

Certification: CE

Model Number: BR-10032

Payment & Shipping Terms

Minimum Order Quantity: 1 set

Price: $68620-86547

Packaging Details: Standard export packing

Delivery Time: 20-30 days

Payment Terms: L/C, T/T, Western Union, D/P, D/A

Supply Ability: 50sets/Year

Get Best Price
Highlight:

Metal Plate Hydraulic CNC Press Brake

,

7.5kw Hydraulic CNC Press Brake

,

4mm Metal Press Bender

Model:
110T3200MM
Max. Bending Thickness:
4mm Carbon Steel 3200mm Width
Controller:
Laimore EL15T
Power:
380v 50hz 3ph
Model:
110T3200MM
Max. Bending Thickness:
4mm Carbon Steel 3200mm Width
Controller:
Laimore EL15T
Power:
380v 50hz 3ph
7.5kw 4mm Hydraulic CNC Press Brake For Metal Plate
7.5kw 4mm Metal Plate CNC Hydraulic Press Brake Bending Machine Metal Press Bender

WC67Y Hydraulic Press brake
1. Steel-welded construction, vibration to eliminate stress, with high strength and good rigidity.
2. Hydualic top-drive, steadiness and reliability. Mechanical stop, steel torsion bar maintain synchronization, high precision.
3. Motorize-adjustinf device of backgauge and rams stroke, fine adjusting by handwheel, numberical display.

HYDRAULIC PRESS BRAKE
1. Adopt integrated hydraulic control system, more reliable and easy for maintenance. main hydraulic valves from Bosch (Germany)
2. All pipes, flange and joint with vibrations proof and leakage proof design and setting .
3. Overload overflow protection is outfitted to hydraulic system,which can assure no leakage,and the oil level can be read or seen directly.
4. The hydraulic system is made in compliance with current regulations.

ELECTRICAL SYSTEM
1. Electrical Cabinet under the international Standard, safe and reliable, strong anti interference capability.
2. Protective fence to ensure the operation safety. Have a movable single-hand pedal switch,easy to operate.

SYNCHRO CONTROL SYSTEM
1. Patented system for exact parallelism and a high repeat accuracy
2. The worktable adopts the particular design,reducing the crowning distortion amount of lower tool effectively.
3. Adopt steel torsion bar synchro system,simple in structure and high in accuracy,ensures the parallelism between beams is used for the synchronism.

RAM AND DIES
1. The equipped difference standard Dies according machine’s model, special non-standard mold is available under client's
requirement according to real workpiece situation.
2. Upper and buttom die can be sectioned according to customer’s requirement.
3. The Machine By CNC Controller or NC Control With the point of programming, can calculate thebending angle bending depth.


Technical Parameters:



Model Norminal pressure (KN) Worktable Length (mm) Columns Distance (mm) Throat Depth (mm) Slider Stroke(mm) Max Open hight (mm) Main motor power(KW) Crowing Cylinders Control Axes X axis stroke(mm) X axis speed(mm/s) Dimension
LxWxH (mm)
WC67Y/K-63/2500 630 2500 1900 350 170 380 5.5 2 3+1 500 200 3100×1450×2050
WC67Y/K-80/3200 800 3200 2700 350 170 380 7.5 3 3+1 500 200 3500×1550×2100
WC67Y/K-100/3200 1000 3200 2700 400 200 420 7.5 3 3+1 500 200 3500×1580×2400
WC67Y/K-160/3200 1600 3200 2700 400 200 420 11 3 3+1 500 200 3500×1650×2550
WC67Y/K-200/3200 2000 3200 2700 400 200 420 15 3 3+1 500 200 3500×1680×2550
WC67Y/K-250/3200 2500 3200 2700 400 200 420 15 3 3+1 500 200 3500×1700×2600
WC67Y/K-320/3200 3200 3200 2700 400 200 420 22 3 3+1 500 200 3500×1800×2730
WC67Y/K-400/4000 4000 4000 3500 500 320 600 30 4 3+1 500 200 4300×2450×3500
WC67Y/K-500/5000 5000 5000 3900 500 320 600 37 / 3+1 800 200 5400×2810×4300
WC67Y/K-500/6000 5000 6000 4900 500 320 600 37 / 3+1 800 200 6500×2810×4300
WC67Y/K-500/7000 5000 7000 4900 500 320 600 37 / 3+1 800 200 7500×2810×4900
WC67Y/K-600/5000 6000 5000 3900 500 320 600 45 / 3+1 800 200 5500×2910×4900
WC67Y/K-600/6000 6000 6000 4900 500 320 600 45 / 3+1 800 200 6500×2910×5100
WC67Y/K-600/7000 6000 7000 5900 500 320 600 45 / 3+1 800 200 7500×2910×5200
WC67Y/K-800/6000 8000 6000 4900 600 400 600 55 / 3+1 800 200 6500×2750 ×5300
WC67Y/K-800/8000 8000 8000 6900 600 400 600 55 / 3+1 800 200 8500×2750×5900
WC67Y/K-1000/6000 10000 6000 4900 600 400 600 2×37 / 3+1 800 200 6500×2800×5600
WC67Y/K-1000/8000 10000 8000 6900 600 400 600 2×37 / 3+1 800 200 8500×2800×6100
WC67Y/K-1000/10000 10000 10000 8000 600 400 600 2×37 / 3+1 800 200 10500×2800×5850
WC67Y/K-1200/6000 12000 6000 4900 600 400 800 2×37 / 3+1 1000 200 6500×3100×5850
WC67Y/K-1200/8000 12000 8000 6900 600 400 800 2×37 / 3+1 1000 200 8500×3100×7150




7.5kw 4mm Hydraulic CNC Press Brake For Metal Plate 0



Details:



Main Configuration
Laimore EL15T CNC Controller
Adopting HIWIN ball screw and linear guide rail, accuracy 0.01mm
Front supporter bracket
Germany Bosch Rexroth hydraulic valve block
Germany EMB oil tube connector
Germany Siemens main motor
France Schneider electrics
Hydraulic & electrical overload protection

Automatic Mechanical compensation
Upper and lower dies(86°, R0.6mm, material: 42CrMo)





Kacon pedal switch
South Korea KACON pedal switch, improving the service life and operational sensitivity

7.5kw 4mm Hydraulic CNC Press Brake For Metal Plate 1



Main servo motor
Power saving



7.5kw 4mm Hydraulic CNC Press Brake For Metal Plate 2



Automatic Bracket

Fully automatic, more high-end, save time and labor!



7.5kw 4mm Hydraulic CNC Press Brake For Metal Plate 3



Ball Screw & Guide LinearBall
Adopt the HIWIN brand from Taiwan Ball Screw and guide linear , promise the high precision and speed when workingAdopt the HIWIN brand from Taiwan Ball Screw and guide linear , promise the high precision and speed when working

7.5kw 4mm Hydraulic CNC Press Brake For Metal Plate 4
